Full Height Turnstile Rugged Weatherproof Access Control For High Security Areas
Product Overview
The Z216 full-height turnstile is engineered for unattended access control in high-security environments. Its non-climbable structure effectively prevents unauthorized entry into restricted zones and eliminates the possibility of climbing over the barrier. Constructed with robust welded stainless steel, this turnstile offers exceptional reliability and vandal resistance, ensuring years of trouble-free operation even in demanding conditions.
Ideal for construction sites, industrial parks, and campuses, the system seamlessly integrates with various identification technologies including facial recognition terminals and card readers, enabling easy upgrades to automated access control or attendance management systems.
Key Features & Benefits
Rugged, Durable 24/7 Protection
Engineered with a reliable structure that operates smoothly with minimal noise. Precision-machined core components ensure low wear and extended service life, meeting high-frequency passage demands while significantly reducing maintenance costs.
Weather-Resistant Indoor & Outdoor Use
Manufactured from waterproof, UV-resistant, cold-resistant, and heat-resistant materials with high IP ratings. Reliable operation in extreme weather conditions including intense sun, heavy rain, severe cold, or extreme heat.
Smart Expandability & Multiple Functions
Seamless integration with identification systems including facial recognition terminals and card readers. Easy upgrade capability to automatic access control or attendance terminals, combining security and management in a single solution.
Power-Fail Safety & Fire Compliance
Automatic unlocking and mechanical mode activation during power failures, allowing free passage and ensuring full compliance with fire safety regulations. Eliminates safety risks and maintains clear emergency exits.
Two-Way Indicators & Clear Guidance
Equipped with bright two-way arrow status indicators providing real-time passage status. Clear red/green visual signals effectively guide pedestrian flow, preventing wrong-way entry and congestion.
Automatic Reset & Anti-Tailgating
Automatic permission cancellation and reset to initial state if authorized users don't pass within set time limits. Prevents permission abuse, improves passage efficiency, and eliminates tailgating risks.
Technical Specifications
| Product Name |
Full Height Turnstile |
| Protection Grade |
IP43, IP54 |
| Communication Interface |
I/O, RS485 |
| Traffic Speed |
30 People/Minute |
| Channel Width |
600mm |
| Rotation Angle Per Step |
90° |
| Barrier Material |
304 stainless steel round tube / 201 stainless steel with baked paint |
| Passage Frame |
304 stainless steel / 201 stainless steel with baked paint |
| Product Size |
1500mm × 2300mm |
| Working Voltage |
220V ±10% |
| Ambient Temperature |
-20℃ to 65℃ |
| Relative Humidity |
≤95% Not Condensing |
| Work Environment |
Indoor and Outdoor |
| Product Power |
50W |
| Access Control Type |
RFID/IC/ID Card, Face/Iris Recognition, Fingerprint Identification, QR Code, Mobile Phone/NFC, Password, Remote Door Opening |
| Communication Interface |
Relay switch signal/12V level signal/12V pulse signal with pulse width >100ms; RS485 or TCP/IP |
Frequently Asked Questions
What is a full height turnstile gate?
A full height turnstile gate is a high-security pedestrian access control barrier that uses full-height rotating arms to prevent unauthorized entry. It is commonly used in places requiring strict security management.
What is the difference between a full height turnstile and a tripod turnstile?
A tripod turnstile only controls access at waist height, while a full height turnstile provides a complete barrier that prevents climbing over or bypassing, making it more suitable for high-security environments.
Can this turnstile work with facial recognition systems?
Yes. The full height turnstile supports integration with facial recognition, fingerprint scanners, RFID readers, QR code systems, and other access control technologies.
Is this turnstile suitable for outdoor use?
Yes. With a durable stainless steel structure and weather-resistant design, it can be installed in outdoor environments such as stadium entrances, factories, and construction sites.
How many people can pass through the turnstile?
The traffic capacity depends on the model and access management settings. It is designed for continuous pedestrian flow in high-volume applications.
Does the turnstile support emergency opening?
Yes. The system can be connected with fire alarm systems and emergency controls to allow rapid evacuation when required.
Why Choose Our Full Height Turnstile Gate?
Selecting the appropriate pedestrian security gate is crucial for protecting your facility. Our full height turnstile system combines mechanical strength, smart access control compatibility, and reliable performance to deliver a professional security entrance solution.
Whether you need access control for a factory, stadium, government building, transportation station, or restricted facility, this high-security turnstile provides an effective way to manage pedestrian access.
Request a Free Quote
Looking for a reliable full height turnstile gate supplier? Contact us today for:
Request your free quote now and improve your facility security with our professional full height turnstile access control system.
